Mini Infrared Thermometer

180D mini infrared thermometer is a non-contact temperature measuring instrument using infrared technology and laser pointer. You can use this product to measure the surface temperature, which is not suitable for traditional measuring (such as moving objects, charged objects, toxic objects or hard-to-reach objects).

The instrument features a low consumption design. It has a LCD with backlight, a laser pointer for accurate aiming and capable of auto holding the readings. It has the advantages of rapid measuring, easy operation and portability. It is widely used for applications such as finding the hot spot of electric connection and bearing, measuring the hot and high-frequency induction heated objects, monitoring food processing and storage, inspecting temperature for heating & refrigeration system, inspecting temperature for technics control of metallurgy industry, inspecting temperature during laying asphalt and fire-control work, or any other temperature measuring without compromising the temperature field. It is a good measuring tool for the metallurgy, the electric power plant, the chemical industry, the rubber industry, the spinning and weaving, the plastic, the papermaking and the food processing.

180D mini infrared thermometer is a Class II laser product and in compliance with EN60825-1 safety standard.

Technical Specifications

Product name

Mini Infrared Thermometer

Model

KC-180D

Measuring range

-30℃~250℃(-22℉~482℉)

Response wavelength

8~14μm

Measuring precision

±2℃(±3.6℉) or ±2%(When T>0℃)



±3℃(±5.4℉) or ±2% whichever is greater  (When T≤0℃)

Repetition

1% of reading or 1℃

Response time

500mSec,95% response

Optical ratio(D:S)

6:1

Emissivity

0.10-1 adjustable

Display resolution

±0.1℃

Laser wavelength

630~660nm

Laser power

<1mW

Laser class

Class II

Data hold

             √

Temperature units exchange

             √

Low battery indication

             √

Auto turn off

No action in 15s

Power supply

Two CR2032 batteries

Max. power

<5 mA(laser off)

Working temperature

0℃~40℃(32℉~104℉)

Working humidity

0~75%RH non-condensing

Storage

-20℃~60℃(-4℉~140℉),≤85%

Dimension(length*width*height)

108 mm×52 mm×25mm

Weight(w/o battery)

About 60g
